Name: JLR Engineering Tool JET Master with Enet WiFi Adapter for JLR MY 2017-2024
SKU: JETMASTER
Availability: InStock

JLR Engineering Tool Options

CCF Editors

We support CCF Editors for JLR from MY 2016 to 2023 Models, they are CCF Tools 4.6, CCF Tools 4.8, and CCF Tools 4.9.

MY2015 – 2023
CCF Editor
CCF Compare
Work with PF SDD

Start from $69

Order now

JET-Pro

JET Pro JLR Engineering Tool Pro supports JLR DOIP vehicles' Diag and coding via JLR Enet without PF or TOPix.

MY 2018 – 2023
Diag Coding
No DOIP PF TOPix
Read/Write in the car

Start $199

Demo Test now

JET-Master

All features from JET-Pro, JET Master full version support JLR programming via Enet, & remote support from us.

All feature JET-Pro
Programming
Used ECUs Prog
All keys were lost Prog

Remote/ $199

Apply for remote

JLR Engineering Tool JET Master with Enet WiFi Adapter for JLR MY 2017-2024

The JLR Engineering Tool Master and JLR Enet WiFi package offer a cost-effective solution for Land Rover and Range Rover diagnostic and coding. This combination is user-friendly and eliminates the need for an expensive Pathfinder and JLR DOIP interface. A JLR TOPIx online account is not required for 2023 vehicle models. The package supports diagnostic and coding functions for JLR models from 2017 to 2023, making it a valuable tool for JLR OEM retrofit projects.

The JLR Enet WiFi is an essential hardware vehicle communication interface for the maintenance workshops of Land Rover and Range Rover vehicles and the JLR owners. The JLR Enet WiFi, which has been dubbed the best Land Rover diagnostic tool, Land Rover OBD2 scanner, and Range Rover OBD2 scanner, is capable of diagnosing a wide variety of Land Rover and Range Rover vehicles, including the Land Rover Discovery 2, making it a versatile device for a variety of maintenance tasks. The JLR Enet WiFi is equipped to reset the 2001 Land Rover Range Rover P38 OBD2 scanner. It is a critical tool for monitoring your vehicle's air suspension, particularly for the Range Rover L322.

Package includes:

JLR Enet WiFI adapter x 1 set
JLR Master Software with License for one-specific System
Free software update within 12 months
Note: You're purchasing a master tool, we are NOT responsible for teaching you how to use the software if you have no experience with JLR coding or programming.
How to setup JET Tools for the first time
All risks and losses are your responsibility. If you need our remote support to program in-car or with job-done assistance in case, please submit your JLR support ticket.
Knowledge Base Tips

Software Features of the JLR Engineering Tool JET Master

CCF flashing, support byte change, VBF import, one-key modification, latest start and stop memory, car lock when away from the car, unlock when near the car, acc, etc. The most important thing is to support all Jaguar Land Rover from 17 years to the present, Including 23 Defenders, the new Range Rover, as long as it is a DOIP vehicle
ECU Module flashing, free IVS import and download the corresponding VBF file, fast flashing, host imc iccm flashing, as long as the 1002 can respond to the module, it can be flashed
Support fault code reading and guidance, according to the topology diagram of the original vehicle configuration module, it is clear at a glance, does not support data flow, and requires command interaction
Quickly use the ECU function, remove the speed limit, maintain the light, mileage, etc.
Model Immobilisers, there are sub-division Immobilisers, and new Immobilisers, one-key shielding TCU, quickly matching key bracelets
Interaction of engineering commands, experts can solve problems remotely and quickly!

7 reasons why you need to order the JET Master tool (sx-tool)?

Cost-effective via Enet connection, no JLR DOIP nor TOPix cloud required
3in1 features Diagnostic Coding Flashing (including Key Programming) for all DoIP-based vehicles, for all keys lost programming like K8D2 RFA module will require to replace the package support KVM+BCM + keys from us.
CCF Editor support till 2023 with one-click Coding Scripts via Enet, Standard VBF Read/Write
the software WON'T be locked to regional use
Support Port Forwarder via specific VPN tools
Constantly Online Update
Optional with our Team technical support

Hardware Features of the JLR Enet WiFi adapter:

Embedded UART-ETH-WIFI module
DC/DC converter for improved power consumption
Additional CPU heat sink for over-temperature protection
2.4GHz 802.11b/g/n compatibility, default password 12345678
Support for IEEE 802.3 and IEEE 802.3u
WiFi Client/AP/Router Mode
Support for WPS/WDS
Baud rate range: 1200~500000bps
Support for transparent transmission mode
Multiple security authentication mechanisms supported: WEP64/WEP128/ TKIP/ AES WEP/WPA-PSK/WPA2-PSK
Wireless roaming support
Support for multiple network protocols: PPPoE/TCP/UDP/DNS/DHCP/DNS/HTTP/Firewire
Support for AT+ instruction set

Why JLR Engineering Tool Pro and JLR Enet WiFi package?

User-friendly software: Easy to use with click and play
cost saving without buying the expensive Pathfinder and JLR DOIP interface
no JLR TOPIx online account required for 2023+ vehicle models
Support JLR 2017 – 2024 models diagnostic and coding functions
the best value tool for JLR OEM retrofit jobs

In addition to the JLR Enet WiFi, the software “JLR Engineering Tool Pro” is optional with limited to one specific VIN (car owner version) to be included for the package, making this a complete diagnostic and maintenance solution for your Land Rover or Range Rover. Whether you're a professional technician or a do-it-yourself enthusiast, the JLR Enet WiFi and JLR Engineering Tool Pro will offer you all the information you need to maintain your vehicle. This potent combination of hardware and software makes the JLR Enet WiFi and JLR Engineering Tool Pro an indispensable tool for maintaining a Land Rover or Range Rover.

OEM ODMs are available, global dealers are WANTED for the best OBD2 scanner for the Land Rover.

A demo token license with full master functions is available to order here for one specific VIN test before you order the official license.

How to use JET Master to flash BCM used in 2mins?

How to Program New JLR Keys in 5Mins with JET Master via Enet

More JLR engineering tool option, PRO or Master?

JET Features

Flashing

Diag & Coding

Key Programming

Used ECU Prog.

CCF Editor to 2024

Self Coding Scripts

VCI Enet/JLR Enet WiFi

VBF Read/Write

Region Locked

Team Tec support

Online Post Update

License Release

Demo Test

Global Dealers

JET Master

YES

Instant

Available

Open

More info

JET Pro

Instant

Available

Open

More info

Notes:

JET Master(SX-Tool) Jaguar Land rover Engineering Tool, Key programming / All keys lost support to 2024, PF = Pathfinder, VCI Enet refers to any normal Enet like BMW Enet cable, Reseller Program is open to JLR people from all over the world.
